Description
The Pixfra Arc range is perfect for:
- Bat surveys of buildings, particularly where a wider field of view is required (A613)
- Bat surveys of more distant structures and trees (remainder of range)
- Nocturnal bird and mammal surveys
- Hunting
- Search & rescue
Manufacturer warranty information
The Pixfra Arc Thermal Monocular is a compact and versatile thermal imaging device designed for wildlife enthusiasts, search and rescue teams, and ecology/conservation professionals. By detecting infrared radiation, it enables observation in complete darkness, fog, or dense vegetation. This monocular is ideal for non-invasive wildlife tracking, long-range detection, and general thermal imaging applications.
The Pixfra Arc A613 has been designed specifically for ecologists, with bat surveys in mind. The wider field of view of 32.3° horizontal x 25.8° vertical, facilitated by a shorter focal length, enables views of larger objects, closer up - perfect for surveying buildings for emerging bats.
Other models in the range have narrower field of view, but are still perfect for bat surveys where the user wishes to target specific roost features, or where it is not possible to position the camera close to the building. All models in this range meet the requirements set out in best practice guidance for bat surveys. Please see the Thermal Imaging: Bat Survey Guidelines published by the Bat Conservation Trust for more advice on how to choose your thermal imaging equipment for bat surveys.
The Arc range is also perfect for other applications, including nocturnal bird surveys, hunting, and search & rescue.
With built-in storage and recording capabilities, users can capture high-resolution thermal footage and images for documentation or review. This feature is particularly useful for surveyors who need to analyse their observations later or keep records of their observations.
Specifications
The Pixfra Arc series includes multiple models to suit different user needs. Below is a comparison of their specifications:
| Feature | PF-A419 | PF-A425 | PF-A435 | PF-A625 | PF-A635 | PF-A613 |
|---|---|---|---|---|---|---|
| Detector type | Vanadium oxide uncooled focal plane detector | |||||
| Effective pixels | 384 × 288 | 384 × 288 | 384 × 288 | 640 × 512 | 640 × 512 | 640 × 512 |
| Pixel pitch | 12 µm | |||||
| Spectral range | 8–14 µm | |||||
| Sensitivity (NETD) | ≤30 mK @ f/1.0 | |||||
| Frame rate | 50 Hz | |||||
| Focal length | 19 mm | 25 mm | 35 mm | 25 mm | 35 mm | 13 mm |
| Field of view | 14.4° x 10.8° | 10.9° x 8.2° | 7.8° x 5.9° | 17.5° x 14.0° | 12.4° x 10.0° | 32.3° x 25.8° |
| Detection range (human) | 1,000 m | 1,300 m | 1,800 m | 1,300 m | 1,800 m | 670 m |
| Magnification | 2.1× | 2.76× | 3.86× | 1.68× | 2.36× | 0.875× |
| Colour palettes | White hot, black hot, iron red, alarm, amber, emerald | |||||
| Close focus distance | 2 m | 0.5m | ||||
| Digital zoom | 1×, 2×, 4×, 8× | |||||
| Display screen | 0.41", OLED | |||||
| Screen resolution | 1440 × 1080 | |||||
| Diopter | –4D to +5D | |||||
| Eye relief | 15 mm | |||||
| Uniformity correction | Auto, manual | |||||
| Storage | Built-in EMMC (32 GB) | |||||
Features
- Includes built-in storage for recording and saving video and image captures
- Uses thermal imaging to detect heat signatures, enabling wildlife observation in low light and through fog or vegetation
- Provides full night vision functionality without the need for ambient light, ideal for night-time use
- Compact and lightweight for easy transport, supporting extended field use without relying on artificial lighting such as infrared lamps
- Designed for a variety of tasks including wildlife monitoring, search and rescue, and general security
- All models are IP67-rated for protection against water and dust, and operate reliably in temperatures ranging from –30°C to +55°C
- Features an intuitive interface with simple controls for effective use in dark or low-light conditions
- Ships with two rechargeable batteries, providing up to 15 hours of continuous use
Additional information
The built-in recording function allows users to document and revisit their observations. Whether for research, evidence collection, or sharing experiences, the ability to store thermal images and videos enhances the usability of the Pixfra Arc Thermal Monocular.
Unlike traditional optics, which depend on visible light, thermal monoculars detect heat signatures, making them ideal for low-light and obstructed conditions. This technology enables effective monitoring through fog, smoke, and vegetation while ensuring minimal disturbance to wildlife.
The Arc range enhances collaborative fieldwork by allowing simultaneous viewing across multiple users. Using the free Pixfra app, the device can stream its live feed to up to four smart devices within a 20-metre range. This enables every group member to observe key moments - such as the emergence of a bat or the movement of a nocturnal mammal -without needing to crowd around a single viewfinder.
The Pixfra app is available free of charge for both Android and iOS platforms.
